Waste Water Treatment Electro Chlorination System

Geemblue Electro Chlorination Systems:

Geemblue’s Electro Chlorination systems utilize electrolysis to generate sodium hypochlorite from brine, resulting in a solution with a concentration of 0.8%. This low-concentration sodium hypochlorite offers several distinct advantages:

1. Minimal Maintenance Requirements:
   The 0.8% sodium hypochlorite solution produced by Geemblue is non-aggressive and low in minerals. This characteristic eliminates the need for extensive cleaning and de-scaling of injection nozzles, streamlining operational maintenance.

2. Stability and Longevity:
   Unlike conventional sodium hypochlorite solutions that can lose up to 20% of their chlorine content during storage, Geemblue’s solution remains stable over months without requiring additives. This stability ensures consistent chlorine levels for effective disinfection.

3. Safety and Operational Efficiency:
   Produced in close proximity to the process, the direct storage and dosing of sodium hypochlorite by Geemblue systems minimize the risk of accidental spillage and exposure to operating personnel, enhancing overall safety protocols.

Main Features:

1. Raw Materials: Utilizes only salt or seawater, which are safe and convenient for transportation and storage, without volatility or toxicity concerns.

2. Electrode Connection: Employs a bipolar electrode connection mode, minimizing heat generation and reducing sodium hypochlorite salt and power consumption.

3. Efficiency Standards:

   • Salt consumption < 3.5kg / kg Cl2 (National standard 4.5)
   • AC Power consumption < 4kw / kg Cl2 (National standard 5)

4. Control System: Equipped with Siemens PLC and touch screen for full automatic control, ensuring operational precision and ease of use.

5. Longevity: Extended lifespan of critical components:

   • Cathode life > 20 years
   • Machine life > 15 years

These features collectively make sodium hypochlorite disinfection a robust choice for water treatment facilities seeking effective, safe, and sustainable disinfection solutions.
