Specilize in Water Treatment & Disinfection Technology
8 Years
| Ask Lasest Price | |
| Brand Name : | Geemblue |
| Model Number : | XFDM01B |
| Certification : | ISO9001 CE |
| Price : | NEGOTIATION |
| Payment Terms : | L/C, T/T, Western Union |
| Supply Ability : | 10 SET/MONTH |
| Delivery Time : | 60-80 work days |
COD Reduction PVA Waste water Treatment System
FLEXIBLE USAGE:explosion-proof case can be made according to requirements;
EASY OPERATION:power integrated switch control, without separate electric control cabinet, easy to operate;
SMALL FLOOR AREA: a single module occupies a small floor area, with a simple appearance and reserved water inlet and outle;
COMPLETE FUNCTIONS:the interior is equipped with a hand pump, temperature and pressure switch, filter, etc., and a circulating barrel externally connected can be used.
Specifications:
| Equipment model | XFDM01B | XFDM02B | XFDM04B |
| Equipment dimension (L×W×H, mm) | 1497 x 1234 x 1897 | 1392 x 1247 x 2048 | 2172 x 1764 x 2666 |
| Operating weight of equipment(kg) | 1275 | 1997 | 1867 |
| Number of modules | 1-slot 2-module | 2-slot 4-module | 4-slot 8-module |
| Anode material | BDD | ||
| Cathode material | Ti | ||
| Area of anode strip(㎡) | 0.88 | 1.75 | 3.5 |
| Treatment capacity(m³/h) | By water quality | ||
| Single-batch processing time(h) | By water quality | ||
| Design circulating flow(m³/h) | 10 | 20 | 30 |
| Head loss at design circulating flow(KPa) | 20 | 20 | 40 |
| Installed power(Kw) | 10 | 20 | 36 |
| Service power(Kw) | ≤7 | ≤12 | ≤26 |
| Current density(mA/c㎡) | ≤70(≤301 A) | ≤70(≤602 A) | ≤70(≤1204 A) |
| Maximum heating power(Kw) | 2.79 | 5.6 | 11.2 |
| Input voltage | AC 380 V/50 Hz | AC 380 V/50 Hz | AC 380 V/50 Hz |
| Power output | DC 500 A/20 V | DC 1000 A/20 V | DC 500 A/72 V |
| Operating ambient temperature | 0 ℃ ~ 40 ℃ | ||
| Relative humidity | ≤90% | ||
| Installation method | Indoor | ||
| Circulating water pump | 40 FPZ-18 | TG - 40032 | TG - 50052 |
| Filter | Bag type 50 μm | ||
| Pressure protection | √ | ||
| Temperature protection | √ | ||
| Inlet diameter | DN50 flange | DN50 flange | DN65 flange |
| Outlet diameter | DN50 flange | DN50 flange | DN65 flange |
|
|
